KSS Original Grease for Miniature Ball Screws

The Grease has high lubrication performance without deteriorating Ball Screw function.

In general, it is known that the operation characteristic of Ball Screws is influenced by properties of Grease. Especially, the stir resistance of Grease influences Ball Screw Torque after applying Grease. Selection of Grease is extremely important in the Miniature Ball Screws. KSS has developed Ball Screw excellent Grease, which has high lubrication performance without deteriorating Ball Screw operation. KSS has also developed its exclusive Grease, which keeps smooth feeling and less contamination under clean room environment. We think the best special Grease is prepared respectively according to customer's usage.

  • Product outline
KSS Original Grease for Miniature Ball Screws
KSS Original Grease for Miniature Ball Screws

1.MSG No.1(45g , 380g) : Positioning usage
2.MSG No.2(45g , 380g) : General usage
3.MCG No.1(45g) : Clean room usage

Inquiry or Request

Support Units for Miniature Ball Screws (Compact type)

This type of Support Unit has features of light-weight & compact profile compared to our conventional Support Units.
Support Units for Ball Screws are all in stock. They fit standardized end-journal for both fixed-side and supported-side.


compact support

For detail of standardized end-journal or mounting procedure,
please click here.


Fixed-side

Pillow type (MSU-xC)

pillow type

This type of Support Unit has features of light-weight & compact profile compared to our conventional Support Units by eliminating extra shape of Housing.

Pre-load controlled Angular Contact Bearings are installed, so Rigidity can be kept high.

Collar and Lock Nut are attached for mounting.

Flange type (MSU-xG)

flange type

This type of Support Unit is Flange type model, which can be mounted on wall surface.

Pre-load controlled Angular Contact Bearings are installed, so Rigidity can be kept high.

Collar and Lock Nut are attached for mounting.

Supported-side

Pillow type(MSU-xCS)

pillow type

This type of Support Unit has features of light-weight & compact profile compared to our conventional Support Units by eliminating extra shape of Housing.

Deep Groove Bearing and Stop ring are attached.

Flange type (MSU-xGS)

flange type

This type of Support Unit is Flange type model, which can be mounted on wall surface.

Deep Groove Bearing and Stop ring are attached.

Bearings for Compact Support Units.

Angular Contact Ball Bearings

Angular Contact Ball Bearings

This series is the Angular Contact Ball Bearings built in fixed side of KSS Compact Support Unit.

This can be provided as a set of DF or DB configuration only.

Deep Groove Bearings

Deep Groove Bearings

This series is the Deep Groove Ball Bearings built in supported side of KSS Compact Support Unit.

This type can be provided as a Bearing itself.

Inquiry or Request

Support Units for Ball Screws (Block type)

Support Units for Ball Screws are all in stock. They fit standardized end-journal for both fixed-side and supported-side.
Product outline

  • Angular Contact Bearings (DF type) installed in fixed-side Support Unit have been set Preload, so that it can be built without any adjustment. In addition, it is easy to install onto Screw Shaft by tightening the Lock-Nut, which is attached.

Fixed-side

EK type

Series list
Catalogue PDF
EK型
  • Deep Groove Bearing is installed in supported-side Support Unit. Housing is designed as compact as possible.

Supported-side

EF type
SUP type

Series list
Catalogue PDF
EF type
Inquiry or Request

Stepping Motor Driver

This series is the recommended Driver for KSS Direct Motor Drive Ball Screws and Actuators. You can choose suitable one based on your usage. This is the merchandize purchased from TECHNO DRIVE Co., Ltd.

http://www.technodrive.com/

Stepping Motor Driver

Standard Products

KR-A5CC (5-phase Full/Half step)

Basic function and low price
SKRA5CC
Specifications
Driving type : Bipolar pentagon constant current drive
Power supply : DC 20 – 35V, max. 2A
Driving current : 0.1-0.9A/phase (0.35A/phase at shipping)
Function : Switching of pulse input style,
  Full/Half step, Automatic current down
  • Catalogue PDF
  • 取扱説明書

KR-A55MC (5-phase Micro-step drive)

Low vibration and smooth drive
KR-A55MC
Specifications
Driving type : Micro-step driving type
Power supply : DC 24V, (DC 20-35V) max. 3A
Driving current : 0.4-1.4A/phase (0.75A/phase at shipping)
Interpolation : 1/1 – 1/250 (16 channels)
Function : Switching of pulse input style,
  Micro-step interpolation, Automatic current down
  • Catalogue PDF
  • manual

KR-A535M (5-phase Micro-step drive)

Low vibration and smooth drive
KR-A535M
Specifications
Driving type : Micro-step driving type
Power supply : AC 100V – 220V (±10%), max. 3A 50/60Hz
Driving current : 0.4-1.4A/phase (0.75A/phase at shipping)
Interpolation : 1/1 – 1/250 (16 channels)
Function : Switching of pulse input style,
  Micro-step interpolation,
  Automatic current down, Switching current,
  Built-in test function, Switching driving power.
  • Catalogue PDF

KS9110 (2-phase step drive)

SKRA5CC

Specifications

Driving type:Chopper mode by Uni-polar constant current

Power supply:DC+24V ±10% 3A Max.

Driving current:0.35~2A Max / phase

Function:Switching of pulse input style, Automatic current down

  • カタログPDF

SD4030B2 (2-phase Micro-step drive)

SD4030B

Specifications

Driving type:Chopper mode by Bi-polar constant current

Power supply:DC+18V~40V

Driving current:0.5~3Apeak(±5%)/phase

Interpolation:1/2~1/64(8 channels)

Function:Micro-step interpolation, Automatic current down

  • カタログPDF
  • 取扱説明書
  • Run current setting

Customized Products

KR-A5M (5-phase Full/Half step)

KR-A5M
Specifications
Driving type : Bipolar pentagon constant current drive
Power supply : DC 24V (DC20-35V), max. 3A
Driving current : 0.5-1.5A/phase (0.75A/phase at shipping)
Function : Switching of pulse input style,
  Full/Half step, Automatic current down
  • Catalogue PDF

KR-A55ME (5-phase Micro-step drive)

KR-A55ME
Specifications
Driving type : Micro-step driving type
Power supply : DC 24V (DC20-35V), max. 3A
Driving current : 0.4-1.4A/phase (0.75A/phase at shipping)
Interpolation : 1/1 – 1/250 (16 channels)
Function : Switching of pulse input style,
  Micro-step interpolation, Automatic current down
  • Catalogue PDF
